| Drawing | Size (Sheave dia.)(mm) | Sheave Qty | Max dia of rope(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | D1(mm) | B(mm) | B1(mm) | B2(mm) | t(mm) | t1(mm) | Hex. Wrench dia.(mm) | Unit Weight(kg) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
75 | 1 | 16 | 14.5 | 237 | 38 | 115 | 59 | 80 | 19 | 18 | 24 | 54 | 1.5 | 1.2 | 500 |
|
75 | 2 | 16 | 14.5 | 237 | 38 | 115 | 59 | 80 | 19 | 18 | 24 | 82 | 1.5 | 1.6 | 500 |
|
100 | 1 | 22 | 16 | 297 | 44 | 143 | 78 | 108 | 22 | 23 | 28 | 62 | 1.5 | 2.2 | 1000 |
|
100 | 2 | 22 | 16 | 297 | 44 | 143 | 78 | 108 | 22 | 23 | 28 | 95 | 1.5 | 3.1 | 1000 |
|
125 | 1 | 25 | 22 | 364 | 54 | 174 | 100 | 135 | 27 | 26 | 32 | 73 | 2 | 4.0 | 1200 |
|
125 | 2 | 25 | 22 | 364 | 54 | 174 | 100 | 135 | 27 | 26 | 32 | 111 | 2 | 5.7 | 1200 |
|
150 | 1 | 30 | 25.5 | 433 | 60 | 204 | 120 | 160 | 30 | 31 | 38 | 82 | 3 | 6.0 | 2,500 |
|
150 | 2 | 30 | 25.5 | 433 | 60 | 204 | 120 | 160 | 30 | 31 | 38 | 130 | 3 | 9.0 | 2,500 |
