| Drawing | Size (Sheave dia.)(mm) | Sheave Qty | Max dia of rope(mm) | d(mm) | L(mm) | L2(mm) | D1(mm) | B(mm) | B1(mm) | B2(mm) | t(mm) | t1(mm) | Hex. Wrench dia.(mm) | Unit Weight(kg) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
75 | 1 | 16 | 22 | 259 | 129 | 59 | 80 | 23 | 18 | 24 | 54 | 1.5 | 1.25 | 500 |
|
75 | 2 | 16 | 22 | 259 | 129 | 59 | 80 | 23 | 18 | 24 | 82 | 1.5 | 1.80 | 500 |
|
100 | 1 | 22 | 32 | 340 | 170 | 78 | 108 | 30 | 23 | 28 | 62 | 1.5 | 2.70 | 1000 |
|
100 | 2 | 22 | 32 | 340 | 170 | 78 | 108 | 30 | 23 | 28 | 95 | 1.5 | 3.75 | 1000 |
Block
