| Drawing | Size (Sheave dia.)(mm) | Max dia of rope(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | D1(mm) | B(mm) | B1(mm) | B2(mm) | t(mm) | t1(mm) | Bearing nom. No. | Unit Weight(kg) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
50 | 14 | 10 | 158 | 29 | 83.5 | 36 | 57 | 14.5 | 13 | 20 | 77 | 6000 | 0.95 | 400 |
|
75 | 16 | 14.5 | 229 | 37.5 | 117 | 59 | 84 | 19 | 16.5 | 24 | 94 | 6002 | 2.35 | 600 |
|
100 | 22 | 16 | 282 | 43 | 114.5 | 78 | 109 | 22 | 19.5 | 28 | 110.5 | 6203 | 4.35 | 1000 |
Block
