| Drawing | Size (Sheave dia.)(mm) | Max dia of rope(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | B(mm) | B1(mm) | t(mm) | t1(mm) | Bearing nom. No. | Unit Weight(kg) | Work Load Limit (t) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
100 | 25 | 25 | 171 | 30 | 60 | 112 | 26 | 31 | 63.5 | 6203 | 2.1 | 1.0 |
Block
Menu
AK Block Type PB-S (Stainless Sheave with Stainless Bearing)
