| Drawing | Size Max S.(mm) | L(mm) | W(mm) | W1(mm) | H1(mm) | H2(mm) | H3(mm) | H4(mm) | A(mm) | B(mm) | Thread dia.(mm) | Unit Weight(g) | Work load (Vertical)(kg) | Work load (Lateral)(kg) | Clamping torque(Nm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
25 | 69.5 | 36 | 56.5 | 23 | 11.5 | 11 | 16.5 | 74.5 | 50 | M12 | 240 | 200 | 40 | 25 |
Clamps
