| Drawing | Size(mm) | d(mm) | d1(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | B2(mm) | T(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (t) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
20 | 24 | 23 | 152 | 104 | 72 | 31 | 58 | 20 | 50 | M24 | 1.9 | 1.7 |
|
22 | 26 | 26 | 170 | 117 | 78 | 34 | 65 | 22 | 55 | M24 | 2 | 2.5 |
|
24 | 30 | 28 | 185 | 126 | 87 | 39 | 70 | 24 | 62 | M30 | 3.8 | 3.4 |
|
28 | 34 | 32 | 212 | 144 | 99 | 43 | 80 | 28 | 70 | M33 | 5.1 | 4.3 |
Shackles
