| Drawing | Size | d(mm) | d1(mm) | d2(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B(mm) | B1(mm) | B2(mm) | B3(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
L | 14 | 7 | 9 | 150.5 | 24 | 112 | 32 | 85 | 32 | 30 | 60 | 1,200 | 2,000 |
| (Lock Pin) | — | — | — | — | — | — | — | — | — | — | — | — | — |
Auto Shackle Type 2 PAT
* Material: Special stainless steel
* This product is fishing gear. Do not use it as a hanging hook for cargo handling.
* The gate may open unintentionally due to physical shock. Be sure to use a lock pin when sudden loads on connecting objects or the hardware are expected, or when the gate does not need to be opened for a long time.
* The lock pin is sold separately. Please check the product number «AK18231B9» in the table below and request a quotation if you need.
*If the gate is released while a load is applied, the main unit may be subjected to strong impact and the product may be damaged, or an accident may occur, such as a released load hitting the surrounding objects or people.
