| Drawing | Size | d(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B(mm) | B1(mm) | B2(mm) | B3(mm) | Hex. Wrench dia.(mm) | Unit Weight(g) | Work Load Limit (t) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
M | 11 | 112 | 20 | 80 | 29 | 58 | 23.5 | 28 | 48 | 5 | 370 | 0.8 |
|
L | 14 | 139 | 29 | 99 | 32 | 72 | 32 | 30 | 63 | 6 | 860 | 1.3 |
Purse Seine Fittings
Menu
Auto Shackle Type 3
