| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | B2(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
6 | 6 | 42 | 30 | 24 | 12 | 21 | 12 | W1/4 | 32 | 90 |
|
8 | 8 | 56 | 40 | 32 | 16 | 28 | 16 | W5/16 | 72 | 140 |
|
10 | 10 | 70 | 50 | 40 | 20 | 35 | 20 | W3/8 | 135 | 200 |
|
12 | 12 | 84 | 60 | 48 | 24 | 42 | 24 | W1/2 | 233 | 280 |
Shackles
