Описание
| Drawing | Size(mm) | d(mm) | d1(mm) | L1(mm) | B1(mm) | S(mm) | D(mm) | D1(mm) | Thread dia.(mm) | Hex. Wrench dia.(mm) | Dia of Chain | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
6 | 6 | 9 | 24 | 12 | 9 | 13 | 8.9 | M6 | 5 | 6 | 33 | 140 |
|
8 | 8 | 11 | 32 | 16 | 12 | 16 | 10.9 | M8 | 6 | 8 | 65 | 220 |
Chain Shackle (Brass Cover)
*Materials: SCS14 (Equal to SUS316), Pin: SUS316, Color: Brass
* The inside diameter of the chain must be bigger than the dimensions shown on the above D1.
