| Drawing | Size(mm) | Dia of Chain | L(mm) | L1(mm) | B(mm) | S(mm) | D(mm) | D1(mm) | Thread dia.(mm) | Hex. Wrench dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 65 | 8 | 23.5 | 8 | 4 | 7.5 | M5 | 2.5 | 45 | 30 |
|
6 | 6 | 75 | 9 | 27 | 9 | 5 | 8.5 | M6 | 3 | 55 | 40 |
Chain Hooks
