| Drawing | Dia of rope(mm) | L(mm) | D(mm) | D1(mm) | Hexagonal wrench | Unit Weight(g) | Clamping torque(Nm) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|
 |
1 | 12 | 6 | 2 | 0.9 | 2 | 0.15 | 10 |
|
1.2/1.5 | 15 | 9 | 3 | 1.5 | 7 | 0.5 | 20/30 |
|
2 | 16 | 10 | 4 | 2 | 8 | 1.2 | 40 |
|
2.5 | 18 | 12 | 5 | 2.5 | 15 | 2.2 | 50 |
|
3 | 20 | 14 | 6 | 2.5 | 17 | 2.2 | 70 |
|
4 | 22 | 17 | 8 | 3 | 27 | 3.5 | 100 |
|
5 | 28 | 19 | 10 | 4 | 39 | 5 | 150 |
|
6 | 32 | 22 | 12 | 5 | 56 | 11 | 200 |
Wire Clips, Wire Clips
