Описание
| Drawing | Size(mm) | L(mm) | L1(mm) | B(mm) | S(mm) | t(mm) | D(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|
 |
M1 | 50 | 39 | 25 | 10 | 5.5 | 6.5 | 20 | 40 |
|
M2 | 69 | 53 | 31 | 11 | 8.5 | 10 | 50 | 50 |
|
M3 | 97 | 78 | 46 | 18 | 10 | 15 | 145 | 60 |
Comma-Shaped Spring Snap with Eye
*Materials: SCS14 (equivalent to SUS316)
Spring: SUS304
