Описание
| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
4 | 4 | 23 | 15 | 16 | 8 | 8 | M4 | 8 | 40 |
|
5 | 5 | 30 | 20 | 20 | 10 | 10 | M5 | 15 | 70 |
|
6 | 6 | 38 | 26 | 24 | 12 | 12 | M6 | 25 | 140 |
|
8 | 8 | 50 | 34 | 33 | 17 | 17 | M8 | 60 | 220 |
|
9 | 9 | 54 | 36 | 36 | 18 | 18 | W3/8 | 80 | 270 |
|
10 | 10 | 58 | 38 | 38 | 18 | 20 | M10 | 105 | 320 |
|
12 | 12 | 72 | 48 | 48 | 24 | 24 | M12 | 195 | 400 |
|
14 | 14 | 90 | 62 | 56 | 28 | 28 | M14 | 325 | 600 |
|
16 | 16 | 96 | 64 | 64 | 32 | 32 | M16 | 445 | 900 |
|
19 | 19 | 115 | 77 | 76 | 38 | 38 | M20 | 775 | 1,100 |
|
22 | 22 | 130 | 86 | 88 | 44 | 44 | M22 | 1,195 | 1,600 |
|
25 | 25 | 145 | 95.5 | 100 | 50 | 50 | M24 | 1,710 | 2,200 |
|
28 | 28 | 162 | 107 | 112 | 56 | 54 | M27 | 2,560 | 3,400 |
|
32 | 32 | 197 | 133 | 130 | 66 | 64 | M33 | 3,750 | 4,300 |
