| Drawing | Size(mm) | d(mm) | d1(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 4 | 5 | 32 | 22 | 21 | 11 | 10 | M5 | 15 | 60 |
|
6 | 5 | 6 | 37 | 25 | 24 | 12 | 12 | M6 | 25 | 110 |
|
8 | 7 | 8 | 48 | 32 | 33 | 17 | 16 | M8 | 56 | 170 |
|
10 | 9 | 10 | 60 | 40 | 40 | 20 | 20 | M10 | 105 | 260 |
|
12 | 11 | 12 | 72 | 48 | 49 | 25 | 24 | M12 | 175 | 320 |
Shackles
