Описание
| Drawing | Size(mm) | d(mm) | d1(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
6 | 6 | 6 | 36 | 24 | 24 | 12 | 12 | W1/4 | 29 | 180 |
|
7 | 8 | 7 | 42 | 28 | 28 | 14 | 14 | W5/16 | 51 | 250 |
|
8 | 8 | 8 | 48 | 32 | 32 | 16 | 16 | W5/16 | 72 | 300 |
|
9 | 10 | 9 | 54 | 36 | 36 | 18 | 18 | W3/8 | 110 | 400 |
|
10 | 10 | 10 | 60 | 40 | 40 | 20 | 20 | W3/8 | 139 | 600 |
|
12 | 12 | 12 | 72 | 48 | 48 | 24 | 24 | W1/2 | 230 | 750 |
|
13 | 13 | 13 | 78 | 52 | 52 | 26 | 26 | W1/2 | 310 | 900 |
|
16 | 16 | 16 | 96 | 64 | 64 | 32 | 32 | W5/8 | 528 | 1,500 |
|
19 | 19 | 19 | 114 | 76 | 76 | 38 | 38 | W3/4 | 994 | 2,000 |
|
22 | 22 | 22 | 132 | 88 | 88 | 44 | 44 | W7/8 | 1,470 | 2,500 |
|
25 | 25 | 25 | 145 | 95.5 | 100 | 50 | 49 | M24 | 2,000 | 3,200 |
|
28 | 28 | 28 | 162 | 107 | 112 | 56 | 54 | M27 | 2,900 | 4,000 |
|
32 | 32 | 32 | 197 | 133 | 130 | 66 | 64 | M33 | 4,900 | 5,000 |
