| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | D(mm) | Thread dia.(mm) | Hex. Wrench dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
7 | 7 | 42 | 28 | 28 | 14 | 14 | W5/16 | 1.5 | 40 | 110 |
|
8 | 8 | 48 | 32 | 32 | 16 | 16 | W5/16 | 2 | 60 | 140 |
|
9 | 9 | 54 | 36 | 36 | 18 | 18 | W3/8 | 2 | 80 | 170 |
|
10 | 10 | 60 | 40 | 40 | 20 | 20 | W3/8 | 2 | 110 | 200 |
|
12 | 12 | 72 | 48 | 48 | 24 | 24 | W1/2 | 2 | 190 | 280 |
|
13 | 13 | 78 | 52 | 52 | 26 | 26 | W1/2 | 2 | 240 | 400 |
|
16 | 16 | 96 | 64 | 64 | 32 | 32 | W5/8 | 2 | 435 | 600 |
|
19 | 19 | 114 | 76 | 76 | 38 | 38 | W3/4 | 2 | 750 | 720 |
Shackles
