Описание
| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | D(mm) | Thread dia.(mm) | Pin (Dia * Length)(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
13 | 13 | 78 | 52 | 52 | 26 | 26 | W1/2 | 3*40L | 245 | 450 |
|
16 | 16 | 96 | 64 | 64 | 32 | 32 | W5/8 | 4*40L | 445 | 900 |
D-Shackle with Square Head Pin and Cotter Pin
*Materials: SCS13 (equivalent to SUS304)
Pin & Cotter pin: SUS304
