| Drawing | Size | d(mm) | L1(mm) | L2(mm) | D(mm) | Thread Dia.(Inch) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|
 |
1/4 | 5 | 29 | 14 | 16 | W1/4 | 15 | 50 |
|
5/16 | 6 | 35 | 15 | 20 | W5/16 | 30 | 80 |
|
3/8 | 8 | 42 | 18 | 25 | W3/8 | 60 | 150 |
|
1/2 | 10 | 52 | 22 | 30 | W1/2 | 125 | 220 |
|
5/8 | 13 | 62 | 27 | 34 | W5/8 | 232 | 450 |
