Eye Bolt(Metric Thread)

Описание

Size(mm)	M(mm)	d(mm)	L(mm)	L1(mm)	D(mm)	t(mm)	Unit Weight(g)
5*30	M5	5.1	30	25	10	5	6
5*40	M5	5.1	40	25	10	5	7
5*50	M5	5.1	50	35	10	5	8
6*30	M6	6.1	30	24	12	6	9
6*40	M6	6.1	40	20	12	6	11
6*50	M6	6.1	50	30	12	6	12
6*80	M6	6.1	80	60	12	6	18
8*30	M8	8.1	30	22	16	8	17
8*40	M8	8.1	40	20	16	8	20
8*50	M8	8.1	50	30	16	8	23
8*70	M8	8.1	70	50	16	8	30
8*90	M8	8.1	90	70	16	8	36
10*40	M10	10.2	40	30	20	10	34
10*50	M10	10.2	50	30	20	10	39
10*60	M10	10.2	60	40	20	10	44
10*70	M10	10.2	70	50	20	10	49
10*80	M10	10.2	80	60	20	10	54
10*90	M10	10.2	90	70	20	10	60
10*100	M10	10.2	100	80	20	10	65
12*50	M12	12.2	50	37	26	12	65
12*60	M12	12.2	60	30	26	12	75
12*70	M12	12.2	70	40	26	12	80
12*80	M12	12.2	80	50	26	12	90
12*100	M12	12.2	100	70	26	12	105
16*50	M16	16.5	50	30	32	16	125
16*60	M16	16.5	60	40	32	16	135
16*70	M16	16.5	70	50	32	16	150
