| Drawing | Dia of rope(mm) | d(mm) | B(mm) | L(mm) | t(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|
 |
1 | 1.3 | 2.2 | 7 | 0.6 | 0.1 |
|
1.5 | 1.7 | 3.4 | 7 | 0.7 | 0.15 |
|
2 | 2.3 | 4.6 | 10 | 1 | 0.42 |
|
2.5 | 2.9 | 5.6 | 18 | 1.1 | 0.9 |
|
3 | 3.5 | 6.8 | 11 | 2 | 1.5 |
|
4 | 4.5 | 9.5 | 16 | 2 | 2 |
