Описание
| Drawing | Size (Sheave dia.)(mm) | L(mm) | L1(mm) | H(mm) | H1(mm) | D1(mm) | B(mm) | P(mm) | P1(mm) | Hole dia.(mm) | Max dia of rope(mm) | Sheave dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
50 | 65 | 34 | 72 | 57 | 40 | 58 | 45.5 | 36 | 6.5 | 8 | 50 | 340 | 200 |
|
75 | 86 | 43 | 104 | 86 | 63 | 84 | 57.5 | 52 | 9 | 10 | 75 | 790 | 300 |
