Описание
| Drawing | Size | L(mm) | B(mm) | P(mm) | P1(mm) | H(mm) | H1(mm) | H2(mm) | D(mm) | Hole dia.(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
SS | 44 | 38 | 29 | 35 | 25.5 | 7.5 | 10.5 | 17 | 3.5 | 23 |
|
S | 57 | 44 | 32 | 45 | 32.5 | 8.5 | 11 | 21 | 4 | 32 |
|
L | 65 | 56 | 42 | 52 | 39 | 7.5 | 10.5 | 25 | 3.6 | 46 |
Flush Lift Pull
*Material: SUS304
