| Drawing | Size | d(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B(mm) | B1(mm) | P(mm) | P1(mm) | Hole dia. (Body)(mm) | l1(mm) | l2(mm) | P2(mm) | P3(mm) | Hole dia. (Hook)(mm) | Unit Weight (Body)(g) | Unit Weight (Hook)(g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
S | 6 | 152 | 95 | 57 | 50 | 50 | 19 | 35 | 35 | 6.2 | 55 | 40 | 32 | 16 | 6.2 | 260 | 50 |
|
M | 9 | 272 | 170 | 102 | 76 | 90 | 25 | 44 | 58 | 8.2 | 60 | 80 | 45 | 32 | 8.2 | 830 | 130 |
Hatch Fittings
