Описание
| Drawing | Size(mm) | L(mm) | L1(mm) | d(mm) | D(mm) | D1(mm) | S(mm) | t(mm) | Thread dia.(mm) | Prep, Hole dia.(mm) | Prep, Hole depth(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 45.5 | 34.5 | 5.5 | 15 | 12 | 9 | 1.9 | M6 | 11 | 30 | 15 | 18 |
|
6 | 53 | 41 | 6 | 19 | 20 | 9 | 2 | M6 | 11 | 30 | 25 | 20 |
Hook Bolt R-Shape
*Materials: SUS304
Anchor Plug: Plated
