| Drawing | Size(mm) | d(mm) | L1(mm) | L2(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|
 |
6 | 5 | 31 | 50 | 15 | M6 | 30 | 50 |
|
8 | 6 | 39 | 60 | 20 | M8 | 55 | 80 |
|
10 | 8 | 48.5 | 80 | 25 | M10 | 110 | 150 |
|
12 | 10 | 61 | 100 | 30 | M12 | 210 | 220 |
|
16 | 12.5 | 72 | 150 | 35 | M16 | 440 | 450 |
Bolts / Nuts
