| Drawing | Size (Sheave dia.)(mm) | Max dia of rope(mm) | L(mm) | L2(mm) | L3(mm) | D1(mm) | B(mm) | t(mm) | t1(mm) | t2(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
25 | 6 | 60 | 33 | 45 | 22 | 27 | 10 | 20 | 6 | 30 | 60 |
|
30 | 6 | 71 | 38 | 57 | 27 | 35 | 10 | 20 | 6 | 40 | 60 |
|
35 | 9 | 82 | 45 | 65 | 31 | 40 | 11 | 20 | 9 | 50 | 60 |
|
40 | 9 | 88 | 46 | 71 | 38 | 44 | 13 | 22 | 9 | 60 | 60 |
Block
