| Drawing | Size (Sheave dia.)(mm) | Max dia of rope(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | D1(mm) | B(mm) | B1(mm) | t(mm) | t1(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
25 | 6 | 5 | 85 | 18 | 56 | 45 | 22 | 27 | 13 | 10 | 18 | 50 | 60 |
|
30 | 6 | 5 | 101 | 18 | 65 | 57 | 27 | 35 | 13 | 10 | 20 | 60 | 60 |
|
35 | 9 | 5 | 106 | 18 | 66 | 65 | 31 | 40 | 13 | 11 | 20 | 70 | 60 |
|
40 | 9 | 5 | 111 | 18 | 65 | 71 | 38 | 44 | 13 | 13 | 22 | 85 | 60 |
