| Drawing | Nominal Dia. (d)(mm) | Inside Dia. D1(mm) | D2(mm) | L(mm) | W(mm) | Work Load Limit (t) | Unit Weight(kg) |
|---|---|---|---|---|---|---|---|
 |
16 | 120 | 36 | 250 | 116 | 0.45 | 1.5 |
|
19 | 130 | 42 | 350 | 119 | 0.7 | 2.7 |
|
22 | 150 | 50 | 450 | 122 | 1 | 4.3 |
|
25 | 175 | 55 | 550 | 125 | 1.25 | 6.4 |
|
25 | 200 | 55 | 550 | 125 | 1.10 | 6.7 |
|
28 | 200 | 100 | 550 | 188 | 1.5 | 9 |
|
32 | 200 | 100 | 550 | 192 | 2 | 11.9 |
Mooring Fittings
