| Drawing | Nominal Dia. (d)(mm) | Inside Dia. D1(mm) | D2(mm) | L(mm) | W(mm) | W1(mm) | Work Load Limit (t) | Unit Weight(kg) |
|---|---|---|---|---|---|---|---|---|
 |
16 | 120 | 32 | 250 | 264 | 100 | 0.45 | 1.9 |
|
19 | 130 | 38 | 300 | 276 | 100 | 0.7 | 3.3 |
|
22 | 150 | 44 | 350 | 288 | 100 | 1 | 5 |
|
25 | 175 | 50 | 400 | 300 | 100 | 1.25 | 7.2 |
|
25 | 200 | 50 | 400 | 300 | 100 | 1.10 | 7.5 |
|
28 | 200 | 100 | 450 | 476 | 100 | 1.5 | 9.7 |
|
32 | 200 | 100 | 450 | 484 | 100 | 2 | 12.8 |
