| Drawing | Nominal Dia. (d)(mm) | Inside Dia. D1(mm) | D2(mm) | L(mm) | W(mm) | A(mm) | B(mm) | Work Load Limit (t) | Unit Weight(kg) |
|---|---|---|---|---|---|---|---|---|---|
 |
16 | 120 | 36 | 250 | 390 | 72 | 64 | 0.45 | 2.1 |
|
19 | 130 | 42 | 300 | 460 | 86 | 76 | 0.7 | 3.4 |
|
22 | 150 | 50 | 350 | 540 | 99 | 88 | 1 | 5.2 |
|
25 | 175 | 55 | 400 | 610 | 113 | 100 | 1.25 | 7.7 |
|
25 | 200 | 55 | 400 | 610 | 113 | 100 | 1.10 | 8.0 |
|
28 | 200 | 100 | 420 | 680 | 150 | 100 | 1.5 | 11.3 |
|
32 | 200 | 100 | 420 | 700 | 150 | 100 | 2 | 15 |
