| Drawing | Size(mm) | d(mm) | L(mm) | B(mm) | B1(mm) | P(mm) | H(mm) | H1(mm) | t(mm) | Hole dia.(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 40 | 13 | 11 | 29.5 | 19.5 | 12.5 | 2 | 4.2 | 3.5 | 11 | 20 |
|
6 | 6 | 60 | 19 | 20 | 46 | 27 | 18 | 3 | 5.2 | 4.1 | 28 | 30 |
|
8 | 8 | 80 | 26 | 22 | 54 | 33 | 22 | 3 | 6.7 | 4.5 | 66 | 40 |
|
9 | 9 | 100 | 32 | 28 | 62 | 38 | 25 | 4 | 8.2 | 5.5 | 123 | 50 |
Pad Eyes
