| Drawing | Size(mm) | d(mm) | L(mm) | B(mm) | P(mm) | S(mm) | H(mm) | H1(mm) | t(mm) | Hole dia.(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 40 | 13 | 29.5 | 10 | 21 | 14 | 2 | 4.2 | 3.5 | 10 | 20 |
|
6 | 6 | 60 | 19 | 46 | 11.5 | 27 | 18 | 3 | 5.2 | 4.1 | 30 | 30 |
|
8 | 8 | 80 | 26 | 54 | 17 | 34.5 | 23.5 | 3 | 6.7 | 4.5 | 62 | 40 |
