Описание
| Drawing | -(mm) | L(mm) | B(mm) | P(mm) | P1(mm) | H(mm) | H1(mm) | H2(mm) | A | Hole dia.(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
22 | 44 | 78 | 61 | 27 | 35 | 8 | 16 | 45 | 5.5 | 185 |
|
25 | 48 | 83 | 66 | 29 | 35 | 8 | 16 | 45 | 6 | 195 |
|
22 | 44 | 78 | 61 | 27 | 43 | 8 | 16 | 60 | 5 | 195 |
|
25 | 48 | 83 | 66 | 29 | 43 | 8 | 16 | 60 | 6 | 205 |
Pipe Joint (Angled Base)
* Materials: SCS14 (equivalent to SUS316)
Set Screw: SUS304
* Set Screws: Hexagon socket set screws (1/4-28 UNF)
* Use a hexagon wrench (1/8″»).
