| Drawing | Size | d(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | A(mm) | B(mm) | B1(mm) | B2(mm) | B3(mm) | D(mm) | Thread dia.(mm) | Hex. Wrench dia.(mm) | Stopper Ring Size | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
M | 13 | 158 | 39 | 128 | 30 | 13 | 58 | 26 | 28 | 52 | 26 | W1/2 | 8 | 8 | 630 | 800 |
|
L | 16 | 194 | 48 | 156 | 32 | 16 | 70 | 32 | 30 | 64 | 32 | W5/8 | 10 | 10 | 1345 | 1300 |
Purse Seine Fittings
