Описание
| Drawing | Size | D(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | A(mm) | A1(mm) | B(mm) | B1(mm) | B2(mm) | B3(mm) | Hex. Wrench dia.(mm) | Unit Weight(g) | Work Load Limit (t) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
120 | 52 | 274 | 129 | 171 | 25 | 65 | 20 | 189 | 71.5 | 120 | 50 | 4.14 | 4.1 | 3.0 |
Purse Ring Type O
The roller edge part covers the body to prevent the body and purse line from rubbing against each other. Moreover, the roofed body prevents nets and ropes from getting caught.
A worn roller can be replaced by using a hexagon wrench. Enabling easy replacement of parts reflects ASANOs policy to have our customers use our products for a long period of time.
*Material: Special stainless steel
Roller shaft/set screw : SUS304
Bush: copper alloy
*Since the roller is made of special stainless steel, so recommended using fiber rope. When using a steel wire rope with this product, there is a possibility the roller will be shaved by wire rope depending on the size of the workload, etc.,
