Purse Ring

Главная / Purse Seine Fittings / Purse Ring

Purse Ring

The large-diameter roller and the large-diameter shaft enlarge the volume and surface area to prevent cracks and lengthen service life. The easy-to-disassemble shaft consists of a bolt and nut, and is double-locked with a rivet and set screw.

The roller edge part covers the body to prevent this part of the body and wire ropes (purse line) from rubbing against each other. Moreover, the roofed body makes it hard for nets and ropes to get caught.

You can open the gate by inserting a round bar about 6mm of diameter to the hole of the lock pin end. You can keep the lock released by inserting the round bar, as shown on the right or by pulling the ring on the lock pin end and rotating the lock pin so that the ring is in the diagonal groove.

*Material
Main body: special stainless steel
Roller: special steel
Roller shaft (bolt, nut)/set screw/spring/double ring: SUS304
Lock pin: special stainless steel

*This product is a fishing gear. Do not use it as a hanging hook for cargo handling.

Категория: Purse Seine Fittings
  • Описание

Описание

Drawing Size(mm) D(mm) L(mm) L1(mm) L2(mm) L3(mm) A(mm) A1(mm) B(mm) B1(mm) B2(mm) S(mm) Double Ring(mm) Unit Weight(kg) Work Load Limit (t)
Drawing 80 58 326 146 209 28 75 20 147 75 50 55 2×25 7.4 2.5
