| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | B(mm) | S(mm) | Thread dia.(mm) | Across Flats of Hex.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 58 | 48 | 11 | 9 | M6 | 8 | 25 | 80 |
|
6 | 6 | 72 | 60 | 13.5 | 13 | M9 | 11 | 45 | 150 |
|
8 | 8 | 90 | 74 | 17 | 16 | M11 | 14 | 100 | 590 |
