| Drawing | Size | d(mm) | d1(mm) | D(mm) | L(mm) | B(mm) | H(mm) | t(mm) | Unit Weight(g) | Work Load Limit (t) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
0.5t | 13 | 11 | 48 | 60 | 30 | 44 | 10 | 400 | 0.5 |
|
1t | 19 | 16 | 70 | 80 | 40 | 61 | 12 | 1,110 | 1.0 |
|
1.5t | 22 | 19 | 80 | 100 | 50 | 71 | 14 | 1,780 | 1.5 |
Mooring Fittings
Menu
Ring Plate Type B
