Описание
| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | B(mm) | P(mm) | H(mm) | t(mm) | Hole dia.(mm) | Unit Weight(g) | Max Dia (Cable)(mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 71 | 33 | 30 | 55 | 22 | 4 | 7 | 90 | 9 |
|
7 | 7 | 96 | 38 | 40 | 77 | 30 | 5 | 8.5 | 205 | 14 |
|
9 | 9 | 122 | 56 | 51 | 102 | 42 | 6 | 10.5 | 410 | 22 |
Rope Hanger
*Material: SUS316
*Rope diameter is the maximum operable diameter.
