Описание
| Drawing | Size(mm) | d(mm) | B1(mm) | H(mm) | H1(mm) | H3(mm) | H2(mm) | t(mm) | D(mm) | D1(mm) | Thread dia.(mm) | Prep, Hole dia.(mm) | Prep, Hole depth(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 14 | 40 | 21.5 | 19.5 | 13 | 2.5 | 33 | 30 | M6 | 11 | 40 | 55 | 20 |
|
6 | 6 | 18 | 48 | 28 | 20 | 19 | 3 | 40 | 35 | M8 | 14 | 45 | 95 | 30 |
|
8 | 8 | 22 | 58 | 31 | 27 | 20 | 3 | 50 | 40 | M10 | 18 |
