Описание
| Drawing | Size(mm) | d(mm) | L1(mm) | B1(mm) | H(mm) | H1(mm) | D(mm) | Unit Weight(kg) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|
 |
6 | 5 | 17 | 16 | 93 | 60 | 75 | 0.12 | 130 |
|
8 | 6 | 20 | 20 | 122 | 75 | 100 | 0.24 | 250 |
|
9 | 8 | 22 | 22 | 136 | 85 | 115 | 0.4 | 290 |
|
10 | 9 | 27 | 24 | 154 | 95 | 125 | 0.64 | 300 |
|
13 | 10 | 35 | 31 | 196 | 120 | 160 | 1.07 | 600 |
|
16 | 13 | 45 | 38 | 244 | 150 | 200 | 2.09 | 1,000 |
|
19 | 16 | 50 | 42 | 294 | 180 | 235 | 3.6 | 1,600 |
|
22 | 19 | 52 | 47 | 328 | 205 | 275 | 5.7 | 2,100 |
|
25 | 22 | 67 | 63 | 380 | 235 | 330 | 9 | 2,600 |
|
28 | 25 | 73 | 70 | 430 | 260 | 345 | 13.4 | 3,200 |
