Описание
| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | B(mm) | B1(mm) | D(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
5 | 5 | 31 | 21 | 18 | 12 | 12 | M5 | 13 | 60 |
|
6 | 6 | 37 | 25 | 22 | 13 | 14 | M6 | 21 | 80 |
|
8 | 8 | 47 | 32 | 27 | 18 | 18 | M8 | 40 | 100 |
Semi Round D-Shackle
*Materials: SCS13 (equivalent to SUS 304)
Pin: SUS304
