| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | S(mm) | P(mm) | D(mm) | E(mm) | E1(mm) | Unit Weight(g) | Work Load Limit (t) |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
0.75t | 9 | 109 | 82 | 19 | 40 | 19 | 16 | 18 | 260 | 0.75 |
|
1.5t | 12 | 141 | 102 | 24 | 50 | 28 | 20 | 27 | 565 | 1.5 |
|
2t | 15 | 167 | 121 | 29 | 60 | 32 | 23 | 31 | 975 | 2 |
|
3t | 17 | 200 | 147 | 33 | 60 | 40 | 29 | 37 | 1,580 | 3 |
