Описание
| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | B(mm) | B1(mm) | S(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
S0 | 3 | 55 | 9 | 48 | 18 | 12 | 4 | 16 | 30 |
|
S1 | 4 | 69 | 11 | 60 | 23 | 13 | 7 | 18 | 40 |
|
S2 | 5 | 83 | 14 | 71 | 28 | 17 | 9 | 41 | 50 |
Snap Hook with Swivel Eye
*Materials: SCS13 (equivalent to SUS304)
Pin & Spring: SUS304
*Do not use under conditions of constant rotation.
