| Drawing | Size(mm) | d(mm) | L(mm) | B(mm) | B1(mm) | P1(mm) | P2(mm) | D(mm) | H(mm) | H1(mm) | t(mm) | Hole dia.(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
4 | 4 | 28 | 25 | 11.5 | 18 | 16 | 30 | 16 | 10 | 2 | 3.3 | 3.1 | 20 | 7 |
|
5 | 5 | 35 | 30 | 15 | 23 | 18 | 30 | 22 | 14 | 3 | 4.2 | 3.5 | 45 | 20 |
|
6 | 6 | 40 | 35 | 20 | 25 | 20 | 35 | 27 | 18 | 3 | 5.2 | 4.1 | 70 | 30 |
|
8 | 8 | 50 | 40 | 22 | 35 | 25 | 40 | 31 | 20 | 3 | 5.2 | 4.1 | 125 | 40 |
|
9 | 9 | 58 | 42 | 28 | 43 | 27 | 50 | 38 | 25 | 4 | 5.2 | 4.5 | 198 | 60 |
|
12 | 12 | 75 | 54 | 36 | 56 | 35 | 60 | 50 | 33 | 5 | 5.7 | 5.1 | 422 | 100 |
Pad Eyes
