| Drawing | Size (Sheave dia.)(mm) | Max dia of rope(mm) | d(mm) | W(mm) | D(mm) | D1(mm) | Unit Weight(g) |
|---|---|---|---|---|---|---|---|
 |
50*20 | 14 | 10 | 20 | 50 | 36 | 160 |
|
75*24 | 16 | 13 | 24 | 75 | 59 | 380 |
|
100*28 | 22 | 16 | 28 | 100 | 78 | 630 |
|
125*32 | 25 | 20 | 32 | 125 | 100 | 940 |
|
150*38 | 30 | 27 | 38 | 150 | 120 | 1,600 |
