| Drawing | Size | d(mm) | d1(mm) | L(mm) | B(mm) | Unit Weight(kg) |
|---|---|---|---|---|---|---|
 |
S | 12 | 9 | 200 | 140 | 0.35 |
|
M | 16 | 12 | 240 | 190 | 0.9 |
|
L | 19 | 16 | 315 | 220 | 1.8 |
|
LL | 22 | 19 | 375 | 250 | 3 |
Hook Anchors
Menu
Subaru Hook Anchor
| Drawing | Size | d(mm) | d1(mm) | L(mm) | B(mm) | Unit Weight(kg) |
|---|---|---|---|---|---|---|
|
S | 12 | 9 | 200 | 140 | 0.35 |
|
M | 16 | 12 | 240 | 190 | 0.9 |
|
L | 19 | 16 | 315 | 220 | 1.8 |
|
LL | 22 | 19 | 375 | 250 | 3 |
