Описание
| Drawing | Size(mm) | d(mm) | d1(mm) | L(mm) | L1(mm) | L2(mm) | L3(mm) | B1(mm) | B2(mm) | Thread dia.(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
6 | 6 | 6 | 62 | 15 | 11 | 51 | 15 | 12 | M6 | 60 | 120 |
|
8 | 8 | 8 | 90 | 22 | 17 | 71 | 21 | 16 | M8 | 150 | 200 |
|
10 | 10 | 10 | 113 | 27 | 22 | 90 | 24 | 20 | M10 | 290 | 300 |
|
13 | 10 | 13 | 138 | 26 | 26 | 108 | 24 | 26 | W1/2 | 500 | 400 |
|
16 | 13 | 16 | 173 | 35 | 33 | 136 | 31 | 32 | W5/8 | 970 | 600 |
|
19 | 16 | 19 | 209 | 41 | 39 | 164 | 38 | 38 | W3/4 | 1,650 | 1,000 |
|
22 | 21 | 22 | 247 | 49 | 45 | 193 | 42 | 44 | W7/8 | 2,650 | 1,600 |
