| Drawing | Size(mm) | d(mm) | L(mm) | L1(mm) | L2(mm) | B(mm) | B1(mm) | S(mm) | Unit Weight(g) | Work Load Limit (kg) |
|---|---|---|---|---|---|---|---|---|---|---|
 |
6 | 5 | 100 | 22 | 87 | 37 | 16 | 10 | 85 | 120 |
|
8 | 6 | 110 | 22 | 98 | 45 | 16 | 12 | 126 | 140 |
|
10 | 8 | 141 | 26 | 122 | 54 | 20 | 15 | 220 | 150 |
|
12 | 10 | 172 | 35 | 148 | 66 | 24 | 17 | 388 | 250 |
|
14 | 13 | 225 | 45 | 195 | 82 | 30 | 21 | 1,000 | 560 |
Snap Hooks
